Dimensions | Basic load ratings | Speed ratings | Bearing No | |||||
dynamic | static | Reference speed | Limiting speed | |||||
d[mm] | D[mm] | H[mm] | H1[mm] | C[kN] | C0[kN] | [r/min] | [r/min] | |
10 | 24 | 9 | 8.71 | 12.2 | 9500 | 13000 | 51100 | |
26 | 11 | 12.7 | 18.6 | 8000 | 11000 | 51200 | ||
12 | 26 | 9 | 10.4 | 16.6 | 9000 | 13000 | 51101 | |
28 | 11 | 13.3 | 20.8 | 8000 | 11000 | 51201 | ||
28 | 11.4 | 13 | 13.3 | 20.8 | 8000 | 11000 | 53201 | |
15 | 28 | 9 | 10.6 | 18.3 | 8500 | 12000 | 51102 | |
32 | 12 | 15.9 | 25 | 7000 | 10000 | 51202 | ||
32 | 13.3 | 15 | 15.9 | 25 | 7000 | 10000 | 53202 | |
17 | 30 | 9 | 11.4 | 21.2 | 8500 | 12000 | 51103 | |
35 | 12 | 16.3 | 27 | 6700 | 9500 | 51203 | ||
35 | 13.2 | 15 | 16.3 | 27 | 6700 | 9500 | 53203 | |
20 | 35 | 10 | 15.1 | 29 | 7500 | 10000 | 51104 | |
40 | 14 | 21.2 | 37.5 | 6000 | 8000 | 51204 | ||
40 | 14.7 | 17 | 21.2 | 37.5 | 5600 | 8000 | 53204 | |
25 | 42 | 11 | 18.2 | 39 | 6300 | 9000 | 51105 | |
47 | 15 | 26.5 | 50 | 5300 | 7500 | 51205 | ||
47 | 16.7 | 19 | 26.5 | 50 | 5000 | 7000 | 53205 | |
52 | 18 | 34.5 | 60 | 4500 | 6300 | 51305 | ||
60 | 24 | 42.3 | 67 | 3600 | 5000 | 51405 | ||
30 | 47 | 11 | 19 | 43 | 6000 | 8500 | 51106 | |
52 | 16 | 25.1 | 51 | 4800 | 6700 | 51206 | ||
52 | 17.8 | 20 | 25.1 | 51 | 4500 | 6300 | 53206 | |
60 | 21 | 35.8 | 65.5 | 3800 | 5300 | 51306 | ||
60 | 22.6 | 25 | 35.8 | 65.5 | 3800 | 5300 | 53306 | |
70 | 28 | 70.2 | 122 | 3000 | 4300 | 51406 | ||
35 | 52 | 12 | 19.9 | 51 | 5600 | 7500 | 51107 | |
62 | 18 | 35.1 | 73.5 | 4000 | 5600 | 51207 | ||
62 | 19.9 | 22 | 35.1 | 73.5 | 4000 | 5600 | 53207 | |
68 | 24 | 49.4 | 96.5 | 3400 | 4800 | 51307 | ||
68 | 25.6 | 28 | 49.4 | 96.5 | 3200 | 4500 | 53307 | |
80 | 32 | 76.1 | 137 | 2600 | 3600 | 51407 | ||
40 | 60 | 13 | 25.5 | 63 | 5000 | 7000 | 51108 | |
68 | 19 | 44.2 | 96.5 | 3800 | 5300 | 51208 | ||
68 | 20.3 | 23 | 44.2 | 96.5 | 3600 | 5300 | 53208 | |
78 | 26 | 61.8 | 122 | 3000 | 4300 | 51308 | ||
78 | 28.5 | 31 | 61.8 | 122 | 2800 | 4000 | 53308 | |
90 | 36 | 95.6 | 183 | 2400 | 3400 | 51408 | ||
90 | 38.2 | 42 | 95.6 | 183 | 2400 | 3200 | 53408 | |
45 | 65 | 14 | 26.5 | 69.5 | 4500 | 6300 | 51109 | |
73 | 20 | 39 | 86.5 | 3600 | 5000 | 51209 | ||
73 | 21.3 | 24 | 39 | 86.5 | 3400 | 4800 | 53209 | |
85 | 28 | 76.1 | 153 | 2800 | 4000 | 51309 | ||
85 | 30.1 | 33 | 76.1 | 153 | 2600 | 3800 | 53309 | |
100 | 39 | 124 | 240 | 2200 | 3000 | 51409 | ||
50 | 70 | 14 | 27 | 75 | 4300 | 6300 | 51110 | |
78 | 22 | 49.4 | 116 | 3400 | 4500 | 51210 | ||
78 | 23.5 | 26 | 49.4 | 116 | 3200 | 4500 | 53210 | |
95 | 31 | 81.9 | 170 | 2600 | 3600 | 51310 | ||
95 | 34.3 | 37 | 81.9 | 170 | 2400 | 3400 | 53310 | |
110 | 43 | 159 | 340 | 2000 | 2800 | 51410 | ||
110 | 45.6 | 50 | 159 | 340 | 1900 | 2600 | 53410 | |
55 | 78 | 16 | 30.2 | 81.5 | 3800 | 5300 | 51111 | |
90 | 25 | 58.5 | 134 | 2800 | 4000 | 51211 | ||
90 | 27.3 | 30 | 58.5 | 134 | 2800 | 3800 | 53211 | |
105 | 35 | 101 | 224 | 2200 | 3200 | 51311 | ||
105 | 39.3 | 42 | 101 | 224 | 2200 | 3000 | 53311 | |
120 | 48 | 195 | 400 | 1800 | 2400 | 51411 | ||
120 | 50.5 | 55 | 195 | 400 | 1700 | 2400 | 53411 | |
60 | 85 | 17 | 41.6 | 122 | 3600 | 5000 | 51112 | |
95 | 26 | 59.2 | 140 | 2800 | 3800 | 51212 | ||
95 | 28 | 31 | 59.2 | 140 | 2600 | 3600 | 53212 | |
110 | 35 | 101 | 224 | 2200 | 3000 | 51312 | ||
110 | 38.3 | 42 | 101 | 224 | 2000 | 3000 | 53312 | |
130 | 51 | 199 | 430 | 1600 | 2200 | 51412 M | ||
130 | 54 | 58 | 199 | 430 | 1600 | 2200 | 53412 M | |
65 | 90 | 18 | 37.7 | 108 | 3400 | 4800 | 51113 | |
100 | 27 | 60.5 | 150 | 2600 | 3600 | 51213 | ||
100 | 28.7 | 32 | 60.5 | 150 | 2600 | 3600 | 53213 | |
115 | 36 | 106 | 240 | 2000 | 3000 | 51313 | ||
115 | 39.4 | 43 | 106 | 240 | 2000 | 2800 | 53313 | |
140 | 56 | 216 | 490 | 1500 | 2200 | 51413 M | ||
70 | 95 | 18 | 40.3 | 120 | 3400 | 4500 | 51114 | |
105 | 27 | 32 | 62.4 | 160 | 2600 | 3600 | 53214 | |
105 | 27 | 62.4 | 160 | 2600 | 3600 | 51214 | ||
125 | 40 | 135 | 320 | 1900 | 2600 | 51314 | ||
125 | 44.2 | 48 | 135 | 320 | 1800 | 2600 | 53314 | |
150 | 60 | 234 | 550 | 1400 | 2000 | 51414 M | ||
150 | 63.6 | 69 | 234 | 550 | 1400 | 2000 | 53414 M | |
75 | 100 | 19 | 44.2 | 134 | 3200 | 4300 | 51115 | |
110 | 27 | 63.7 | 170 | 2400 | 3400 | 51215 | ||
110 | 28.3 | 32 | 63.7 | 170 | 2400 | 3400 | 53215 | |
135 | 44 | 163 | 390 | 1700 | 2400 | 51315 | ||
135 | 48.1 | 52 | 163 | 390 | 1700 | 2400 | 53315 | |
160 | 65 | 251 | 610 | 1300 | 1800 | 51415 M | ||
160 | 69 | 75 | 251 | 610 | 1300 | 1800 | 53415 M | |
80 | 105 | 19 | 44.9 | 140 | 3000 | 4300 | 51116 | |
115 | 28 | 76.1 | 208 | 2400 | 3400 | 51216 | ||
115 | 29.5 | 33 | 76.1 | 208 | 2400 | 3200 | 53216 | |
140 | 44 | 159 | 390 | 1700 | 2400 | 51316 | ||
140 | 47.6 | 52 | 159 | 390 | 1600 | 2200 | 53316 | |
170 | 68 | 302 | 750 | 1200 | 1700 | 51416 M | ||
85 | 110 | 19 | 44.9 | 146 | 3000 | 4300 | 51117 | |
125 | 31 | 97.5 | 275 | 2200 | 3000 | 51217 | ||
125 | 33.1 | 37 | 97.5 | 275 | 2000 | 3000 | 53217 | |
150 | 49 | 174 | 405 | 1600 | 2200 | 51317 | ||
150 | 53.1 | 58 | 174 | 405 | 1500 | 2000 | 53317 | |
180 | 72 | 286 | 750 | 1200 | 1600 | 51417 M | ||
90 | 120 | 22 | 59.2 | 208 | 2600 | 3800 | 51118 | |
135 | 35 | 112 | 290 | 2000 | 2800 | 51218 | ||
135 | 38.5 | 42 | 112 | 290 | 1900 | 2600 | 53218 | |
155 | 50 | 182 | 440 | 1500 | 2200 | 51318 | ||
155 | 54.6 | 59 | 182 | 440 | 1400 | 2000 | 53318 | |
190 | 77 | 307 | 815 | 1100 | 1500 | 51418 M | ||
190 | 81.2 | 88 | 307 | 815 | 1100 | 1500 | 53418 M | |
100 | 135 | 25 | 80.6 | 265 | 2400 | 3200 | 51120 | |
150 | 38 | 119 | 325 | 1800 | 2400 | 51220 | ||
150 | 40.9 | 45 | 119 | 325 | 1700 | 2400 | 53220 | |
170 | 55 | 225 | 570 | 1400 | 1900 | 51320 | ||
170 | 59.2 | 64 | 225 | 570 | 1300 | 1800 | 53320 | |
210 | 85 | 371 | 1060 | 950 | 1400 | 51420 M | ||
210 | 90 | 98 | 371 | 1060 | 950 | 1300 | 53420 M | |
110 | 145 | 25 | 83.2 | 285 | 2200 | 3200 | 51122 | |
160 | 38 | 125 | 365 | 1700 | 2400 | 51222 | ||
160 | 40.2 | 45 | 125 | 365 | 1700 | 2400 | 53222 | |
190 | 63 | 291 | 800 | 1200 | 1700 | 51322 M | ||
190 | 67.2 | 72 | 291 | 800 | 1200 | 1600 | 53322 M | |
230 | 95 | 410 | 1220 | 900 | 1300 | 51422 M | ||
120 | 155 | 25 | 85.2 | 305 | 2200 | 3000 | 51124 | |
170 | 39 | 127 | 390 | 1600 | 2200 | 51224 | ||
210 | 70 | 332 | 980 | 1100 | 1500 | 51324 M | ||
210 | 74.1 | 80 | 332 | 980 | 1000 | 1500 | 53324 M | |
250 | 102 | 432 | 1320 | 800 | 1100 | 51424 M | ||
130 | 170 | 30 | 119 | 440 | 1900 | 2600 | 51126 | |
190 | 45 | 186 | 585 | 1400 | 2000 | 51226 | ||
190 | 47.9 | 53 | 186 | 585 | 1300 | 1800 | 53226 | |
225 | 75 | 351 | 1060 | 1000 | 1400 | 51326 M | ||
270 | 110 | 520 | 1730 | 750 | 1000 | 51426 M | ||
140 | 180 | 31 | 111 | 440 | 1800 | 2600 | 51128 | |
200 | 46 | 208 | 630 | 1400 | 1900 | 51228 | ||
200 | 48.6 | 55 | 190 | 620 | 1300 | 1800 | 53228 | |
240 | 80 | 416 | 1370 | 950 | 1300 | 51328 M | ||
280 | 112 | 520 | 1730 | 700 | 1000 | 51428 M | ||
150 | 190 | 31 | 111 | 440 | 1700 | 2400 | 51130 M | |
215 | 50 | 247 | 800 | 1300 | 1800 | 51230 M | ||
250 | 80 | 423 | 1460 | 900 | 1300 | 51330 M | ||
300 | 120 | 559 | 1960 | 670 | 950 | 51430 M | ||
160 | 200 | 31 | 112 | 465 | 1700 | 2400 | 51132 M | |
225 | 51 | 247 | 800 | 1200 | 1700 | 51232 M | ||
270 | 87 | 442 | 1600 | 850 | 1200 | 51332 M | ||
170 | 215 | 34 | 133 | 540 | 1600 | 2200 | 51134 M | |
240 | 55 | 281 | 980 | 1100 | 1600 | 51234 M | ||
280 | 87 | 449 | 1700 | 800 | 1100 | 51334 M | ||
180 | 225 | 34 | 135 | 570 | 1500 | 2200 | 51136 M | |
250 | 56 | 296 | 1080 | 1100 | 1500 | 51236 M | ||
300 | 95 | 520 | 2000 | 750 | 1100 | 51336 M | ||
190 | 240 | 37 | 172 | 710 | 1400 | 2000 | 51138 M | |
270 | 62 | 338 | 1250 | 1000 | 1400 | 51238 M | ||
320 | 105 | 559 | 2200 | 700 | 950 | 51338 M | ||
200 | 250 | 37 | 168 | 710 | 1400 | 1900 | 51140 M | |
280 | 62 | 332 | 1250 | 1000 | 1400 | 51240 M | ||
340 | 110 | 624 | 2600 | 630 | 900 | 51340 M | ||
220 | 270 | 37 | 178 | 800 | 1300 | 1900 | 51144 M | |
300 | 63 | 358 | 1460 | 950 | 1300 | 51244 M | ||
240 | 300 | 45 | 234 | 1040 | 1100 | 1600 | 51148 M | |
340 | 78 | 449 | 1960 | 800 | 1100 | 51248 M | ||
260 | 320 | 45 | 238 | 1100 | 1100 | 1500 | 51152 M | |
360 | 79 | 488 | 2240 | 750 | 1100 | 51252 M | ||
280 | 350 | 53 | 319 | 1460 | 950 | 1300 | 51156 M | |
380 | 80 | 488 | 2320 | 750 | 1000 | 51256 M | ||
300 | 380 | 62 | 364 | 1760 | 850 | 1200 | 51160 M | |
420 | 95 | 585 | 3000 | 630 | 850 | 51260 M |
