Stainless steel Self-Alignment Pillow Block Units UCFC series

Stainless steel Self-Alignment Pillow Block Units UCFC series

SYSTEM DESCRIPTION:

0

TECHNICAL DRAWING:

PDF-Download

PRODUCT DETAILS:

Bearing Unit No. Bore Dia Dimensions(mm) Bearing No. Housing No. Weight
in mm a p e i f g j N K E S (kg)
SUCFC201   12 100 78 55.1 10 62 20.5 5 12 7 28.3 12.7 SUC201 SFC203 0.56
SUCFC201-8  1/2   SUC201-8 SFC203 0.56
SUCFC202   15 SUC202 SFC203 0.56
SUCFC202-10  5/8   SUC202-10 SFC203 0.56
SUCFC203   17 SUC203 SFC203 0.56
SUCFC203-11 11/28   SUC203-11 SFC203 0.56
SUCFC204   20 100 78 55.1 10 62 20.5 5 12 7 28.3 12.7 SUC204 SFC204 0.52
SUCFC204-12 3/4   SUC204-12 SFC204 0.52
SUCFC205   25 115 90 63.6 10 70 21 6 12 7 29.8 14.3 SUC205 SFC205 0.64
SUCFC205-14 7/8   SUC205-14 SFC205 0.64
SUCFC205-15 15/16   SUC205-15 SFC205 0.64
SUCFC205-16 1   SUC205-16 SFC205 0.64
SUCFC206   30 125 100 70.7 10 80 23 8 12 8 32.2 15.9 SUC206 SFC206 0.93
SUCFC206-17 1-11/16   SUC206-17 SFC206 0.93
SUCFC206-18 1-1/8   SUC206-18 SFC206 0.93
SUCFC206-19 1-3/16   SUC206-19 SFC206 0.93
SUCFC206-20 1-1/4   SUC206-20 SFC206 0.93
SUCFC207   35 135 110 77.8 11 90 26 8 14 9 36.4 17.5 SUC207 SFC207 1.2
SUCFC207-20 1-1/4   SUC207-20 SFC207 1.2
SUCFC207-21 15/16   SUC207-21 SFC207 1.2
SUCFC207-22 1-3/8   SUC207-22 SFC207 1.2
SUCFC207-23 1-7/16   SUC207-23 SFC207 1.2
SUCFC208   40 145 120 84.8 11 100 26 10 14 9 41.2 19 SUC208 SFC208 1.59
SUCFC208-24 1-1/2   SUC208-24 SFC208 1.59
SUCFC208-25 1-9/16   SUC208-25 SFC208 1.59
SUCFC209   45 160 132 93.3 10 105 26 12 16 14 40.2 19 SUC209 SFC209 1.84
SUCFC209-26 1-5/8   SUC209-26 SFC209 1.84
SUCFC209-27 1-11/16   SUC209-27 SFC209 1.84
SUCFC209-28 1-3/4   SUC209-28 SFC209 1.84
SUCFC210   50 165 138 97.6 10 110 28 12 16 14 42.6 19 SUC210 SFC210 2.15
SUCFC210-30 1-7/8   SUC210-30 SFC210 2.15
SUCFC210-31 1-15/16   SUC210-31 SFC210 2.15
SUCFC211   55 185 150 106.1 13 125 31 12 19 15 46.4 22.2 SUC211 SFC211 3.1
SUCFC211-32 2   SUC211-32 SFC211 3.1
SUCFC211-34 2-1/8   SUC211-34 SFC211 3.1
SUCFC211-35 2-3/16   SUC211-35 SFC211 3.1
SUCFC212   60 195 160 113.1 17 135 36 12 19 15 56.7 25.4 SUC212 SFC212 3.99
SUCFC212-36 2-1/4   SUC212-36 SFC212 3.99
SUCFC212-38 2-3/8   SUC212-38 SFC212 3.99
SUCFC212-39 2-7/16   SUC212-39 SFC212 3.99
SUCFC213   65 205 170 120.2 16 145 36 14 19 15 55.7 25.4 SUC213 SFC213 4.96
SUCFC213-40 2-1/2   SUC213-40 SFC213 4.96
SUCFC213-41 2-9/16   SUC213-41 SFC213 4.96
SUCFC214   70 215 177 125.1 17 150 40 14 19 18 61.4 30.2 SUC214 SFC214 5.6
SUCFC214-42 2-5/8   SUC214-42 SFC214 5.6
SUCFC214-43 2-11/16   SUC214-43 SFC214 5.6
SUCFC214-44 2-3/4   SUC214-44 SFC214 5.6
SUCFC215   75 220 184 130.1 18 160 40 16 19 18 62.5 33.3 SUC215 SFC215 6.21
SUCFC215-45 2-13/16   SUC215-45 SFC215 6.21
SUCFC215-46 2-7/8   SUC215-46 SFC215 6.21
SUCFC215-47 2-15/16   SUC215-47 SFC215 6.21
SUCFC215-48 3   SUC215-48 SFC215 6.21
SUCFC216   80 240 200 141.4 18 170 42 16 23 18 67.3 33.3 SUC216 SFC216 7.69
SUCFC216-50 3-1/8   SUC216-50 SFC216 7.69
SUCFC217   85 250 208 147.1 18 180 45 18 23 20 69.6 34.1 SUC217 SFC217 9.15
SUCFC217-52 3-1/4   SUC217-52 SFC217 9.15
SUCFC218   90 265 220 155.5 22 190 50 18 23 20 78.3 39.7 SUC218 SFC218 10.95
SUCFC218-56 3-1/2   SUC218-56 SFC218 10.95





AISI 440C Material:

Higher resistance to rust and corrosion than 52100 chrome bearing steel, Please note that AISI 440C will have magnetic properties.

Chemical Composition: C:0.95-1.20, Si≤1.00，Mn≤1.00, P≤0.04, S≤0.03, Cr:16.0-18.0,Mo:≤0.75



AISI 304 Material:

AISI 304 stainless steel, widely used as corrosion- and heat-resistant steel and also as nonmagnetic steel, is most suitable in corrosive environments where
AISI 440C stainless steel can not be used.

Chemical Composition: C≤0.08, Si≤0.75，Mn≤2.00, P：0.045, S：0.03, Cr:18.0-20.0,Mo:8.0-10.5，Ni≤0.10



AISI 316L Material:

316L stainless which provides superior corrosion resistance when compared to conventional steel and 440 stainless bearings.

316L Stainless is the standard molybdenum-bearing stainless steel. The molybdenum gives 316 better overall corrosion resistant properties than Grade 304,
particularly higher resistance to pitting and crevice corrosion in chloride environments.

Chemical Composition: C≤0.03, Si≤1.00，Mn≤2.00, P≤0.045, S≤0.03, Cr:16.0-18.0,Mo:2.0-3.0, Ni:10.0-14.0



Packing

Tube packing, single box packing or other industrial packing are all available.Special requirements should be mentioned in the order

Our own NSJ package is as below
